Product recommendation 200

posted by  Swedish Baklava on  Thu Oct 3 18:32 CST 2013
Author: [PROFILE] [EVERY POST] [THREADS] [BEST POSTS] RSS Feed     [IGNORE ALL POSTS]
last visit: Fri Oct 24 06:40 CST 2014
[RELATED]

Hi All,

I used this tool to do followings...

1. cam shaft gear counter hold tool
2. intermediate shaft gear counter hold tool
3. gland nut counter hold tool + used a 24" long pipe wrench. They came out without trying too hard.

I will be using this tool for rear pinion gear + tail shaft job in the future. Wish me luck.

http://www.amazon.com/OTC-4754-Universal-Pulley-Holder/dp/B000Q8GVPY/ref=sr_1_1?ie=UTF8&qid=1380846180&sr=8-1&keywords=adjustable+crank+holder+tool

--

Thank you all!

ktuuri, Sil, Oleseahorse, pinetucky, riverbend, bulletproof, sideswipe, kittygreysvolvo, Steve, Ken C, Goatman, alschnertz, DELOC, volvorelix, james_a_sousa, Onkel Udo II, vvpete, nick 2012, joekidd, ted, Art Benstein, scorron, derek uk, Volvo from Heck, TONY H, raidman, j.pelchat, JohnMc, Paulii, CB, philsmith, porkface, pageda, 1990Volvo240, Bill D, leugim, Xraybob, keithostertag, jwalker, dobber13, lucid, matt82dl, 740_dan, Trev29, trichard, Rene, transit wind, machine man, mr.zorak, brick lover, Nel621, stevepenniman, BrickDad, Volvodad, John McPhail, Senn14, aleekat, Patrol, BonesandFeathers, hawkeye, Will740turbo, Flyboyk, javalion, laharview, john sargent, Milanomike, H4L.9000, ricko, DELOC, hardknocks!, Ihealey, benski, BORK^3, mtd240, Clarmstr, chup, berlis, wetback85, jwheli, darkdelta, Ryan_R, boxvolvo, p1800nut, Erling, vigilante, 7dddd, oldduke, KlausC, Jorrell, anthony2, Bradley, Andrew in AL, 240GT, RicoS, bob, Jac912, 81242DLB21FCA, Chris Mullet, rancher rick, Rludwick, SPOOK, Don Foster and Dave Shannon.








  •   REPLY TO THIS MESSAGE    PRINT   SAVE

    Product Spec II 200

    posted by  Swedish Baklava on  Thu Dec 19 19:18 CST 2013
    Author: [PROFILE] [EVERY POST] [THREADS] [BEST POSTS] RSS Feed     [IGNORE ALL POSTS]
    last visit: Fri Oct 24 06:40 CST 2014
    [RELATED]

    Hi all,

    FYI.

    photo steppins_zpsa636399e.jpg

    photo pulleyholder_zps2463136f.jpg


    Hi Phil,

    I sent you the same high rez files to your email.








    •   REPLY TO THIS MESSAGE    PRINT   SAVE

      Product Spec II 200

      posted by  transit wind on  Mon Dec 23 01:19 CST 2013
      Author: [PROFILE] [EVERY POST] [THREADS] [BEST POSTS] RSS Feed     [IGNORE ALL POSTS]
      last visit: Fri Aug 15 22:40 CST 2014
      [RELATED]

      A cheaper tool to use for loosening the Cam and Intermediate gears is a strap wrench. Got a nice one from Sears for like $12. Has worked really well for me. Its compact and light enough to keep stored in my tool box which I keep in my wagon at all times. Plus 3 feet of rope for the crank pulley.








  •   REPLY TO THIS MESSAGE    PRINT   SAVE

    for the tailshaft bushing 200

    posted by  trichard on  Tue Oct 29 12:04 CST 2013
    Author: [PROFILE] [EVERY POST] [THREADS] [BEST POSTS] RSS Feed     [IGNORE ALL POSTS]
    last visit: Fri Oct 24 05:52 CST 2014
    [RELATED]

    this is the only tool worth finding or using.
    no longer made by ramac industries this tool was given away FREE by them in the 1990's for every 25 seals you bought to do this job.

    the sold it for 350 dollars otherwise.

    using it takes all of 20 minutes and no mess to remove the bushing and re install







  •   REPLY TO THIS MESSAGE    PRINT   SAVE

    Product Spec 200

    posted by  Swedish Baklava on  Mon Oct 28 18:55 CST 2013
    Author: [PROFILE] [EVERY POST] [THREADS] [BEST POSTS] RSS Feed     [IGNORE ALL POSTS]
    last visit: Fri Oct 24 06:40 CST 2014
    [RELATED]

    Hi Phil,

    FYI. The bar is 1/4" thk. The holes can be drilled in various sizes.

    photo bar_zps84aced30.jpg








    •   REPLY TO THIS MESSAGE    PRINT   SAVE

      Product Spec 200

      posted by  machine man on  Tue Oct 29 14:45 CST 2013
      Author: [PROFILE] [EVERY POST] [THREADS] [BEST POSTS] RSS Feed     [IGNORE ALL POSTS]
      last visit: Wed Oct 22 15:40 CST 2014
      [RELATED]

      Thanks for coming through on this.

      I will store it with my "other" to do "someday" projects!

      If you have time you could throw in some loose descriptions or approximate dimensions of that accessory pin collection that came with it.
      Close up pictures will work as I can vary things so it's not copying for any kind of production scheme per say!

      I might even be able to blow up the picture of the tool if I try!

      I am not into mental sabotage of any patents but may have been sabotaged mentally! (:-)
      Thanks again,
      Phil








    •   REPLY TO THIS MESSAGE    PRINT   SAVE

      Product Spec 200

      posted by  benski on  Tue Oct 29 00:34 CST 2013
      Author: [PROFILE] [EVERY POST] [THREADS] [BEST POSTS] RSS Feed     [IGNORE ALL POSTS]
      last visit: Wed Oct 22 12:07 CST 2014
      [RELATED]

      I like all the OTC stuff I've got. Sturdy and usually well designed. As a bargain, maybe not. As a good value, probably so. If it gets you on your way with the job at hand, perhaps it borders on priceless...:)








  •   REPLY TO THIS MESSAGE    PRINT   SAVE

    Product recommendation 200 1981

    posted by  81242DLB21FCA on  Fri Oct 4 04:15 CST 2013
    Author: [PROFILE] [EVERY POST] [THREADS] [BEST POSTS] RSS Feed     [IGNORE ALL POSTS]
    last visit: Thu Oct 23 22:26 CST 2014
    [RELATED]

    Glad to hear it worked well. I do think $60 for two bars bolted together is just silly.








    •   REPLY TO THIS MESSAGE    PRINT   SAVE

      Product recommendation 200 1981

      posted by  Swedish Baklava on  Sat Oct 5 06:48 CST 2013
      Author: [PROFILE] [EVERY POST] [THREADS] [BEST POSTS] RSS Feed     [IGNORE ALL POSTS]
      last visit: Fri Oct 24 06:40 CST 2014
      [RELATED]

      Hi 81242DLB21FCA,

      When I ran out all the BB tricks to loosen the cam/inter gears, I had no choice but to get one. For a beginner like myself, this is a good tool to have since one can focus on fixing a car and not worry about making a tool. I have found ways to utilize it in many ways but I still can't over how much this cost. Very expensive and silly indeed...








      •   REPLY TO THIS MESSAGE    PRINT   SAVE

        Product recommendation 200 1981

        posted by  scorron on  Sat Oct 5 07:10 CST 2013
        Author: [PROFILE] [EVERY POST] [THREADS] [BEST POSTS] RSS Feed     [IGNORE ALL POSTS]
        last visit: Tue Oct 7 21:10 CST 2014
        [RELATED]

        Looks like it took the place of several other tools that, altogether, would have cost more. And seems versatile enough to adapt to even more situations. I'd say it was a good purchase.








        •   REPLY TO THIS MESSAGE    PRINT   SAVE

          Product recommendation 200 1981

          posted by  Swedish Baklava on  Sat Oct 5 10:12 CST 2013
          Author: [PROFILE] [EVERY POST] [THREADS] [BEST POSTS] RSS Feed     [IGNORE ALL POSTS]
          last visit: Fri Oct 24 06:40 CST 2014
          [RELATED]

          Sean, Thank you. I do feel a little better. I will do a spec drawing and post them up later.








          •   REPLY TO THIS MESSAGE    PRINT   SAVE

            Product recommendation 200 1981

            posted by  machine man on  Sat Oct 5 17:45 CST 2013
            Author: [PROFILE] [EVERY POST] [THREADS] [BEST POSTS] RSS Feed     [IGNORE ALL POSTS]
            last visit: Wed Oct 22 15:40 CST 2014
            [RELATED]

            I will be looking for that bit of information. Thanks for thinking that way. Saves me from standing there measuring and making paper or mental notes in the store.

            I like OTC tools, as they make nice things but "some" seem to be priced well over their tooling up and R&D cost. OTC means to me....Outrageous Tooling Cost. Just an opinion of a machine head. (:-)

            Looks like something from Harbor Freight but I am sure their metal and workmanship is higher!

            In fact, you would probably catch me thinking of chain link fencing material to make it out of!
            You know those flat "galvanized" tensioning rods you weave into the openings to pull on between posts.
            Cheap and cheesy but tough in their intended direction. A couple bucks and you get four feet. Enough to probably make two of these!

            Phil







<< < > >>
