Four weeks ago I bought a Swagman 64650 to carry two bikes from a receiver hitch mount. I've not actually used it yet -- just installed it and tested Mrs. B's ability to load and remove bikes. She has a ladies' model with no top bar, so that was my main consideration in choosing this particular rack -- the tires sit in amply-sized loops so the padded upper clamp is not so critical for strength.
To get in the hatch, the bikes need to be removed. The rack's vertical post folds, but folds to the side, so the rack doesn't need to be removed for hatch access, just the bikes.
The 64650 is made from 1" square tubing. It will fit those 1-1/4" receivers, and to fit my 2", it comes with sturdy, solid aluminum L-shaped spacers to make a sleeve where it goes in the receiver. It comes with an anti-rattle hitch pin, which is just a threaded pin that sucks down a piece of close-fitting square stock inside the tube.
My 64650 arrived with one manufacturing defect. That insert for the anti-rattle pin was only tapped two threads. Probably an NC operation, and the part being made when the tap broke got tossed in the wrong box. I made the mistake of eyeballing the pin and pronouncing it 1/2"-13 and proceeded to tap the insert with a standard UNC tap.
Imagine my surprise when I found the pin is actually threaded 12 TPI (no, not 2mm), so I had to find a fully threaded 1/2"-13 bolt to use as a hitch pin, and settle for grade 5. The bolt worked, but I am guessing I just removed any and all product liability from Swagman by the compromise.
Aside from that minor glitch, which I should have solved by calling Swagman, the product passed my scrutiny. I have a set of used Thule roof bars I think highly of, but I can't send Mrs. B off somewhere with bikes on the roof.
--
Art Benstein near Baltimore
